Focus ADF Welding Helmet

81910900

The Focus ADF welding helmet is ideal for hobby and workshop use and light industrial welding. The helmet features a fully automatic True Colour filter and is certified according to EN379, EN175 and EN166.

Find a dealer

No description found.

Article number	Type	Product Name
81910860	Accessories		Focus Hard Hat
81910861	Accessories		Adapter for Mounting of Hard Hat

Article number	Type	Replacement interval
81910906	Spare Parts	Sweat Frontlet
81910904	Spare Parts	ADF Mounting Frame Assembly
81910801	Spare Parts	Protection Glass (External, 85.9 x 103.6 mm)
81910802	Spare Parts	Protection Glass (Internal, 53.7 x 104.8 mm)

Specification	Value
Viewing Area	97 x 47 mm
Cartridge Size	110 x 90 x 9 mm
UV/IR Protection	Permanent DIN Shade 16
Light State	DIN 4
Dark State	DIN 9-13 variable
Grinding	Yes
Power Supply	Solar Cell with Built-in Battery
Power On/Off	Fully Automatic
Switching Time	Light to Dark <1/30,000s
Dark to Light	0.1 - 1.0s (Internal Variable)
Operating Temperature	-5 °C to +55 °C
Storage Temperature	-20 ºC to +70 ºC
Helmet Material	High Impact Polyamide (Nylon)
Total Weight	540 g
Minimum Operating Amperage	10 Amps
Classification	1/1/1/2
Approved	EN175, EN379, EN166
